The Klockner Moeller DILM25-21 (415V50Hz, 480V60Hz)
is a 3-phase IEC rated contactor
used for the control of electric
motors. It is rated 7.5 HP at 230V
and 15 HP at 460V. It comes with
2NO and 1NC auxiliary contact.
Conforms to IEC 60947
Product Specifications
| Product Attribute | Attribute Value |
| Amp ratings : AC1 | 40 |
| Three phase HP ratings : 230V | 7.5 |
| Three phase HP ratings : 460V | 15 |
| Auxiliary contacts : NO | 2 |
| Auxiliary contacts : NC | 1 |
| Coil Voltage / AC Voltage | 415V50HZ, 480V60HZ |
| Catalog No. | DILM25-21(415V50HZ, 48060HZ) |
