The Klockner Moeller PKZM0-6,3 is a
3 phase thermal-magnetic motor protective device
incorporating adjustable bimetal trips for motor
overload protections and magnetic trips to de-energize
the motor circuit in case of a short circuit.
Product Specifications
| Product Attribute | Attribute Value |
| Rated Un-interrupted Current | 6.3 |
| Setting:Overload Releases | 4 - 6.3 |
| Setting:Short Circuit Releases | 8 |
| Maximum HP Three phase:200V | 1 |
| Maximum HP Three phase:240V | 1.5 |
| Maximum HP Three phase:480V | 3 |
| Maximum HP Three phase:600V | 5 |
| Catalog No. | PKZM0-6,3 |
